Name: 2EDGVHM35 300V double row Pluggable Terminal Blocks supplyer
Brand: Shanye
Price: 1 USD

Model : 2EDGVHM-3.5

Brand : SHAN YE

Conductor Size : 0.2-6.0

Type : Pluggable

Material : PA66plastic,UL94V-0 ,Copper alloy

Color : Green,other color can custom

Place of Origin : China

Brand Name : Shanye

Price : negotiable

Packaging Details : carton box

Payment Terms : Western Union, , T/T

Contact Now

Product Specifications

Pitch	3.5mm
Poles	2P-24P
Number of Contacts	2-24
Rated voltage	300V
Reated current	8A
Pin Dimensions) [mm	3.7
Temperature range	-40°C~+105°C
(Impulse wiithstand voltagea) [KV]	2.5
Supply Ability	100000 Piece/ per Week
Stripping Length) [mm]	15-16
Contactive Coating	Tin Plated
Withstanding VoltagWithstanding Voltag	2200V/1Min
PCB Hole Diameter) [mm]	1.4

Product Application
